车辆进小区的瓶颈效应及其对路段交通流的影响

doi:10.12066/j.issn.1007-2861.2292

上海大学学报(自然科学版) ›› 2022, Vol. 28 ›› Issue (2): 215-225.doi: 10.12066/j.issn.1007-2861.2292

车辆进小区的瓶颈效应及其对路段交通流的影响

盛哲¹, 周文海¹, 高庆飞¹, 董力耘¹^,²()

1.上海大学力学与工程科学学院, 上海市应用数学和力学研究所, 上海 200072
2.上海市力学在能源工程中的应用重点实验室, 上海 200072

收稿日期:2021-02-22 出版日期:2022-04-30 发布日期:2022-04-28
通讯作者: 董力耘 E-mail:dly@shu.edu.cn
作者简介:董力耘(1971--), 男, 副教授, 博士, 研究方向为交通流动力学. E-mail: dly@shu.edu.cn
基金资助:
国家自然科学基金资助项目(11572184)

Traffic bottleneck induced by vehicles entering residential areas and its effect on road capacity

SHENG Zhe¹, ZHOU Wenhai¹, GAO Qingfei¹, DONG Liyun¹^,²()

1. Shanghai Institute of Applied Mathematics and Mechanics, School of Mechanics and Engineering Science, Shanghai University, Shanghai 200072, China
2. Shanghai Key Laboratory of Mechanics in Energy Engineering, Shanghai 200072, China

Received:2021-02-22 Online:2022-04-30 Published:2022-04-28
Contact: DONG Liyun E-mail:dly@shu.edu.cn

摘要/Abstract

摘要：

车辆提前减速进入居民小区会形成一个交通瓶颈, 尤其在晚高峰期间会明显降低道路通行能力. 基于考虑慢启动效应的 VDR(velocity dependent randomization) 模型, 并引入期望时间反映车辆进入小区前的提前减速行为, 研究了单向单车道和双向两车道两种情况. 模拟结果显示: 当入区概率较大时, 存在一个临界进车概率, 当进车概率大于临界值时, 出现一个流量平台. 临界进车概率及其对应的流量值随入区概率的增加而减小; 当进车概率小于临界值时, 双向两车道系统流量要大于单向单车道. 双向两车道时路段上存在 3 个瓶颈, 即小区入口以及上下游路口. 小区入口与路口保持一定距离, 可减少瓶颈之间的干扰, 则小区入口位置的变化对道路通行能力的影响不明显.

关键词: 元胞自动机, VDR 模型, 交通瓶颈, 路段通行能力

Abstract:

Vehicles decelerate in advance when entering a residential area, forming traffic bottlenecks. Especially in evening peaks, vehicles returning to residential areas will significantly reduce road capacity. This paper introduces anticipation time to reflect the deceleration behavior of vehicles before entering the residential area based on the velocity-dependent randomization (VDR) model. Both the one-way, single-lane system and the two-way, two-lane system are studied in this paper. The simulation results show that there is a critical injection probability when the entry probability is large enough. When the injection probability is greater than the critical value, a traffic platform appears. The critical injection probability and its corresponding flux value decrease with increasing the entry probability. When the injection probability is less than the critical value, the flux in the two-way, two-lane system is greater than that in the one-way, single-lane system. There are three bottlenecks in the two-way, two-lane system: the entrance to the residential area and the upstream and downstream ends of the road. When the entrance to the residential area is not close to the ends of the road, the influence of the entrance location on road capacity is negligible.

Key words: cellular automata, velocity-dependent randomization (VDR) model, traffic bottleneck, road capacity

中图分类号:

盛哲, 周文海, 高庆飞, 董力耘. 车辆进小区的瓶颈效应及其对路段交通流的影响[J]. 上海大学学报(自然科学版), 2022, 28(2): 215-225.

SHENG Zhe, ZHOU Wenhai, GAO Qingfei, DONG Liyun. Traffic bottleneck induced by vehicles entering residential areas and its effect on road capacity[J]. Journal of Shanghai University（Natural Science Edition）, 2022, 28(2): 215-225.

图/表 10

图1

图2

图3

图4

图5

图6

图7

图8

图9

图10

参考文献 17

[1]	Diedrich G, Santen L, Schadschneider A, et al. Effects of on- and off-ramps in cellular automata models for traffic flow[J]. International Journal of Modern Physics C, 2000, 11(2): 335-345.
[2]	Huang D W. Effects of ramps in the Nagel-Schreckenberg traffic model[J]. International Journal of Modern Physics C, 2002, 13(6): 739-749. doi: 10.1142/S0129183102003541
[3]	Jia B, Jiang R, Wu Q S. Traffic behavior near an off ramp in the cellular automaton traffic model[J]. Physical Review E, 2004, 69(6): 056105. doi: 10.1103/PhysRevE.69.056105
[4]	Ez-Zahraouy H, Benrihane Z, Benyoussef A. The effect of off-ramp on the one-dimensional cellular automaton traffic flow with open boundaries[J]. International Journal of Modern Physics B, 2004, 18(16): 2347-2360. doi: 10.1142/S021797920402610X
[5]	江金胜, 董力耘. 双下匝道系统的交通流动态特征及其优化[J]. 物理学报, 2012, 61(21): 214503.
[6]	康瑞, 杨凯. 敏感换道对下匝道系统交通流的影响[J]. 物理学报, 2013, 62(23): 238901.
[7]	Liu X H, Ko H T, Guo M M, et al. A new traffic model on compulsive lane-changing caused by off-ramp[J]. Chinese Physics B, 2016, 25(4): 048901. doi: 10.1088/1674-1056/25/4/048901
[8]	Dong C Y, Wang H, Li Y, et al. Application of machine learning algorithms in lane-changing model for intelligent vehicles exiting to off-ramp[J]. Transportmetrica A: Transport Science, 2021, 17: 124-150. doi: 10.1080/23249935.2020.1746861
[9]	Lee H W, Popkov V, Kim D. Two-way traffic flow: exactly solvable model of traffic jam[J]. Journal of Physics A: Mathematical and General, 1997, 30(24): 8497-8513. doi: 10.1088/0305-4470/30/24/014
[10]	Fouladvand M E, Lee H W. Exactly solvable two-way traffic model with ordered sequential update[J]. Physical Review E, 1999, 60(6): 6465. doi: 10.1103/PhysRevE.60.6465
[11]	Popkov V, Peschel I. Exactly solvable statistical model for two-way traffic[J]. Journal of Physics A: Mathematical and General, 2000, 33: 3989-3995. doi: 10.1088/0305-4470/33/22/303
[12]	Appert-Rolland C, Hilhorst H J, Schehr G. Spontaneous symmetry breaking in a two-lane model for bidirectional overtaking traffic[J]. Journal of Statistical Mechanics, 2010(8): P08024.
[13]	Simon P M, Gutowitz H A. Cellular automaton model for bidirectional traffic[J]. Physical Review E, 1998, 57(2): 2441-2444. doi: 10.1103/PhysRevE.57.2441
[14]	郑容森, 谭惠丽, 孔令江, 等. 双向两车道混合车辆交通流的特性[J]. 物理学报, 2005, 54(10): 4614-4620.
[15]	Moussa N. Simon-Gutowitz bidirectional traffic model revisited[J]. Physics Letters A, 2008, 372(45): 6701-6704. doi: 10.1016/j.physleta.2008.08.081
[16]	Moussa N. Simulation study of traffic accidents in bidirectional traffic models[J]. International Journal of Modern Physics C, 2010, 21(12): 1501-1515. doi: 10.1142/S0129183110016007
[17]	Echab H, Marzoug R, Lakouari N, et al. Studies of vehicle overtaking dynamics and its influence on traffic flow at a bidirectional road[J]. International Journal of Modern Physics C, 2017, 28(6): 1750077. doi: 10.1142/S0129183117500772
