一种基于电学法的高准度水汽透过率测试模型

doi:10.12066/j.issn.1007-2861.2174

上海大学学报(自然科学版) ›› 2021, Vol. 27 ›› Issue (4): 677-685.doi: 10.12066/j.issn.1007-2861.2174

一种基于电学法的高准度水汽透过率测试模型

李泽文¹^,², 张建华¹^,², 郭爱英²()

1.上海大学机电工程与自动化学院, 上海 200444
2.上海大学新型显示与系统集成教育部重点实验室, 上海 200444

收稿日期:2018-11-27 出版日期:2021-08-20 发布日期:2021-07-22
通讯作者: 郭爱英 E-mail:gayshh@shu.edu.cn
作者简介:郭爱英(1972—), 女, 教授, 博士, 研究方向为 OLED 新型显示、高功率 LED 和薄膜技术等. E-mail: gayshh@shu.edu.cn
基金资助:
上海市科委重大基础研究资助项目(18JC1410402);上海市科委重大基础研究资助项目(16JC1400602)

Development of high-accuracy water-vapor transmission rate test model using electrical method

LI Zewen¹^,², ZHANG Jianhua¹^,², GUO Aiying²()

1. School of Mechatronics and Automation, Shanghai University, Shanghai 200444, China
2. Key Laboratories of Advanced Display and System Application, Shanghai University, Shanghai 200444, China

Received:2018-11-27 Online:2021-08-20 Published:2021-07-22
Contact: GUO Aiying E-mail:gayshh@shu.edu.cn

摘要/Abstract

摘要：

针对传统电学法水汽透过率(water vapor transmission rate, WVTR)测试高精度、低准度的问题, 提出了一种电流分布特性修正的高准度 WVTR 测试模型, 并基于此测试模型设计了一套完整的、易于使用的 WVTR 测试系统. 系统硬件采用了便于维护的高适应性夹具、全封闭测试环境等设计, 软件采用了多线程、时间误差补偿、自适应修正等算法. 理论分析和实际测试结果表明, 修正后的 WVTR 测试模型及测试系统实现了兼具使用成本低和高精度、高准度的设计目标.

关键词: 封装, 水汽透过率, 电学法, 误差补偿

Abstract:

A high-precision problem of the traditional electrical method for determining the water-vapor transmission rate (WVTR) was analysed, and a high-accuracy WVTR test model with current distribution characteristics correction was developed. Based on the test model, a complete and simple WVTR test system was designed. The system hardware required high-adaptive fixtures for easy maintenance and a fully enclosed test environment, and the software included multi-threading, time-error compensation, and adaptive correction algorithms. The theoretical analysis and experimental test results showed that the modified WVTR test model and system satisfied the design requirements of low costs, high precision, and high accuracy.

Key words: encapsulation, water-vapor transmission rate (WVTR), electrical method, error compensation

中图分类号:

TP273
TP274

李泽文, 张建华, 郭爱英. 一种基于电学法的高准度水汽透过率测试模型[J]. 上海大学学报(自然科学版), 2021, 27(4): 677-685.

LI Zewen, ZHANG Jianhua, GUO Aiying. Development of high-accuracy water-vapor transmission rate test model using electrical method[J]. Journal of Shanghai University（Natural Science Edition）, 2021, 27(4): 677-685.

图/表 7

图1

图2

图3

图4

图5

图6

图7

参考文献 13

[1]	Han H B, Tu Z L, Wu Z G, et al. Green iridium complexes based on pyrimidine derivatives for efficient electroluminescence with EQE near 30%[J]. Dyes and Pigments, 2019, 160(1):863-871. doi: 10.1016/j.dyepig.2018.09.017
[2]	Wang Z, Liu F, Zheng X, et al. Study on luminescence characteristics of blue OLED with phosphor-doped host-guest structure[J]. Optoelectronics Letters, 2018, 14(3):164-169. doi: 10.1007/s11801-018-7266-z
[3]	Wang Q, Ma D. Management of charges and excitons for high-performance white organic light-emitting diodes[J]. Chemical Society Reviews, 2010, 39(7):2387-2398. doi: 10.1039/b909057f
[4]	陈欣, 于佳佳, 管善国, 等. 增重法与减重法在不同包装材料中的应用[J]. 包装工程, 2018, 39(1):97-100.
	Chen X, Yu J J, Guan S G, et al. Application of desiccant method and water method in different packaging materials[J]. Packaging Engineering, 2018, 39(1):97-100.
[5]	王瑞雪. 以聚乙烯亚胺作为电子注入层的有机发光器件[D]. 重庆: 西南大学, 2015.
	Wang R X. Organic light-emitting diodes based on polythylenimine ethoxylated electron injection layer[D]. Chongqin: Southwest University, 2015.
[6]	高清泽. 卡尔费休双通道微量水分测定仪构建技术研究[D]. 天津: 天津大学, 2012.
	Gao Q Z. The construction technology research of Karl Fischer two-channel instrument for measuring trace water[D]. Tianjin: Tianjin University, 2012.
[7]	Radovanovic Z, Golubovic A, Plzak A, et al. Blue dye versus combined blue dye-radioactive tracer technique in detection of sentinel lymph node in breast cancer[J]. European Journal of Surgical Oncology, 2004, 30(9):913-917. doi: 10.1016/j.ejso.2004.08.003
[8]	Kim L H, Jeong Y J, An T K, et al. Optimization of Al$_{ 2}$O$_{ 3}$/TiO$_{ 2}$ nanolaminate thin films prepared with different oxide ratios, for use in organic light-emitting diode encapsulation, via plasma-enhanced atomic layer deposition[J]. Physical Chemistry Chemical Physics, 2015, 18(2):1042. doi: 10.1039/C5CP06713H
[9]	Shen K. Chemical analysis method for carbon bearing refractory products: determination of the total carbon by combustion gravimetric method[J]. Chinas Refractories, 2007, 16(1):34-36.
[10]	MOCON Inc. Best material size for permeation testing[EB/OL]. [2019-03-08]. http://www.mocon.com/consulting-and-testing-services/standard-permeation-testing.html.
[11]	Sun F B, Duan Y, Yang Y Q, et al. Fabrication of tunable [Al$_{ 2}$O$_{ 3}$:alucone] thin-film encapsulations for topemitting organic light-emitting diodes with high performance optical and barrier properties[J]. Organic Electronics, 2014, 15(10):2546-2552. doi: 10.1016/j.orgel.2014.07.004
[12]	Xiao W, Hui D Y, Zheng C, et al. A flexible transparent gas barrier film employing the method of mixing ALD/MLD-grown Al$_{2}$O$_{3}$ and alucone layers[J]. Nanoscale Research Letters, 2015, 10(1):130. doi: 10.1186/s11671-015-0838-y
[13]	Yang Y Q, Yu D, Duan Y H, et al. High barrier properties of transparent thin-film encapsulations for top emission organic light-emitting diodes[J]. Organic Electronics, 2014, 15(6):1120-1125. doi: 10.1016/j.orgel.2014.03.007
