新型多孔聚苯胺在超级电容器电极材料中的应用

doi:10.12066/j.issn.1007-2861.2116

上海大学学报(自然科学版) ›› 2021, Vol. 27 ›› Issue (1): 154-160.doi: 10.12066/j.issn.1007-2861.2116

新型多孔聚苯胺在超级电容器电极材料中的应用

琚歌¹, KHAN Muhammad Arif², 郑惠文¹, 安仲勋¹^,³, 吴明霞¹^,³, 赵宏滨¹(), 徐甲强¹

1.上海大学理学院, 上海 200444
2.上海大学材料科学与工程学院, 上海 200444
3.上海奥威科技发展有限公司, 上海 201203

收稿日期:2019-01-02 出版日期:2021-02-28 发布日期:2021-02-28
通讯作者: 赵宏滨 E-mail:hongbinzhao@shu.edu.cn
作者简介:赵宏滨(1974---), 男, 教授, 博士生导师, 博士, 研究方向为无机功能材料的制备及应用. E-mail: hongbinzhao@shu.edu.cn
基金资助:
国家重点研发计划资助项目(2017YEB0102200);国家重点研发计划资助项目(2017YFB0102900);上海市浦江人才计划资助项目(17PJD016)

Application of novel porous polyaniline in electrode material of supercapacitor

JU Ge¹, KHAN Muhammad Arif², ZHENG Huiwen¹, AN Zhongxun¹^,³, WU Mingxia¹^,³, ZHAO Hongbin¹(), XU Jiaqiang¹

1. College of Sciences, Shanghai University, Shanghai 200444, China
2. School of Materials Science and Engineering, Shanghai University, Shanghai 200444, China
3. Shanghai Aowei Technology Development Co., Ltd., Shanghai 201203, China

Received:2019-01-02 Online:2021-02-28 Published:2021-02-28
Contact: ZHAO Hongbin E-mail:hongbinzhao@shu.edu.cn

摘要/Abstract

摘要：

通过一个简便的方法, 将苯胺单体在含氯化钾 (KCl) 的盐酸溶液中聚合制备出多孔聚苯胺 (polyaniline, PANI). 以 KCl 作为形成多孔聚苯胺的赝模板, 既有效地避免了有机溶剂和硬/软模板的使用, 又减轻了对环境的污染. 由于具有独特的多孔结构和相互交错的纳米棒结构, 多孔聚苯胺的比表面积较大, 显示出良好的电化学性能. 电化学测试结果表明: 当 KCl 添加至饱和态时, 所制备的多孔聚苯胺电极表现出 800 F$\cdot$g$^{-1}$ 的高比电容, 是普通聚苯胺 (不使用 KCl 作为赝模板) 的 6 倍多, 显示出多孔聚苯胺在超级电容器方面的应用潜力.

关键词: 聚苯胺, 多孔, 超级电容器, 电化学性能

Abstract:

Porous polyaniline (PANI) is prepared through an efficient and cost-effective method by polymerisation of aniline in a HCl solution containing KCl. The KCl solution serves as a pseudo-template for the formation of porous PANI, thereby avoiding the use of organic solvents and hard/soft templates and thus protecting the environment. Because of its highly porous structure and intercrossed nanorods, PANI provides a large surface area, resulting in good electrochemical performance. The porous PANI electrodes show a high specific capacitance of 800 F$\cdot$g-1 prepared with saturated KCl, which is more than six times than that of PANI prepared without KCl as the pseudo-template. Thus, synthesised PANI is an excellent electrode material for supercapacitors and is of great significance in their practical application.

Key words: polyaniline (PANI), porous, supercapacitors, electrochemical property

中图分类号:

TP212.1

琚歌, KHAN Muhammad Arif, 郑惠文, 安仲勋, 吴明霞, 赵宏滨, 徐甲强. 新型多孔聚苯胺在超级电容器电极材料中的应用[J]. 上海大学学报(自然科学版), 2021, 27(1): 154-160.

JU Ge, KHAN Muhammad Arif, ZHENG Huiwen, AN Zhongxun, WU Mingxia, ZHAO Hongbin, XU Jiaqiang. Application of novel porous polyaniline in electrode material of supercapacitor[J]. Journal of Shanghai University（Natural Science Edition）, 2021, 27(1): 154-160.

图/表 5

参考文献 14

[1]	Huang Y, Tang Z J, Liu Z X, et al. Toward enhancing wearability and fashion of wearable supercapacitor with modified polyurethane artificial leather electrolyte[J]. Nano-Micro Letters, 2018,10(3):38. doi: 10.1007/s40820-018-0191-7 pmid: 30393687
[2]	Pei Z B, Hu H B, Liang G J, et al. Carbon-based flexible and all-solid-state micro-supercapacitors fabricated by inkjet printing with enhanced performance[J]. Nano-Micro Letters, 2017,9(2):19. doi: 10.1007/s40820-016-0119-z pmid: 30460315
[3]	Bhadra S, Khastgir D, Singha N K, et al. Progress in preparation, processing and applications of polyaniline[J]. Progress in Polymer Science, 2009,34(8):783-810. doi: 10.1016/j.progpolymsci.2009.04.003
[4]	Chiou N R, Epstein A J. Polyaniline nanofibers prepared by dilute polymerization[J]. Advanced Materials, 2005,17(13):1679-1683. doi: 10.1002/(ISSN)1521-4095
[5]	Li D, Huang J X, Kaner R B. Polyaniline nanofibers: a unique polymer nanostructure for versatile applications[J]. ChemInform, 2009. DOI: 10.1002/chin.200916271.
[6]	Wang Y Q, Shi Y, Pan L J, et al. Dopant-enabled supramolecular approach for controlled synjournal of nanostructured conductive polymer hydrogels[J]. Nano Letters, 2015,15(11):7736-7741. doi: 10.1021/acs.nanolett.5b03891 pmid: 26505784
[7]	Pan L, Yu G, Zhai D, et al. Hierarchical nanostructured conducting polymer hydrogel with high electrochemical activity[J]. Proceedings of the National Academy of Sciences of the United States of America, 2012,109(24):9287-9292. doi: 10.1073/pnas.1202636109 pmid: 22645374
[8]	Tong Y J, Huang W X, Luo J, et al. Synjournal and properties of aromatic polyimides derived from 2,2,3,3-biphenyltetracarboxylic dianhydride[J]. Journal of Polymer Science Part A: Polymer Chemistry, 1999,37(10):1425-1433. doi: 10.1002/(ISSN)1099-0518
[9]	Pirhady T N, Ghorbani M, Shojaei A. Controlled growth of hollow polyaniline structures: from nanotubes to microspheres[J]. Polymer, 2013,54(21):5586-5594. doi: 10.1016/j.polymer.2013.07.071
[10]	Zhang X, Zhu J H, Haldolaarachchige N, et al. Synthetic process engineered polyaniline nanostructures with tunable morphology and physical properties[J]. Polymer, 2012,53(10):2109-2120.
[11]	Amarnath C A, Kim J, Kim K, et al. Nanoflakes to nanorods and nanospheres transition of selenious acid doped polyaniline[J]. Polymer, 2008,49(2):432-437.
[12]	Huang J X, Moore J A, Acquaye J H, et al. Mechanochemical route to the conducting polymer polyaniline[J]. Macromolecules, 2005,38(2):317-321. doi: 10.1021/ma049711y
[13]	Wei Z X, Zhang Z M, Wan M X. Formation mechanism of self-assembled polyaniline micro/nanotubes[J]. Langmuir, 2002,18(3):917-921.
[14]	Cho S, Shin K H, Jang J. Enhanced electrochemical performance of highly porous supercapacitor electrodes based on solution processed polyaniline thin films[J]. Applied Materials & Interfaces, 2013,5(18):9186-9193. doi: 10.1021/am402702y pmid: 24032539
