发动机爆震室气相化学反应机理及爆轰波性质的数值研究

doi:10.12066/j.issn.1007-2861.2216

Abstract

Abstract:

The strong nonlinear coupling of gas dynamics and chemical reactions exists in the structure of detonation wave. Based on sensitivity analysis, a 20-step element reaction model and 9-step reaction model are utilized with Euler equations. Roe scheme is used to solve the convective term and second order upwind format is used for interpolation. A numerical study on the detonation of H₂/O₂ in a pulse detonation engine is conducted. Calculated detonation parameters agree with CJ theory and experimental data, which show that the physical models with chemical reactions used in this study are correct. In addition, the detonation cellular structure is numerically analyzed. The 20-step reaction model can describe the collision and evolution of the triple point more accurately than the 9-step reaction model. It can also better explain the decoupling between reaction zone and incident shock wave as well as strong coupling with Mach stem. Therefore, the effects of inert-gas (Ar) dilution and the initial pressure of the gas phase on detonation in a detonation chamber are discussed based on the 20-step reaction model.

Key words: element reaction, sensitivity analysis, detonation cellular structure, triple point collision

CLC Number:

O381

RAO Feixiong, DING Jue, WENG Peifen, LI Xiaowei. Numerical study on gasous chemical reaction mechanism and detonation wave in the detonation chamber of engine[J]. Journal of Shanghai University（Natural Science Edition）, 2020, 26(4): 606-616.

Figures/Tables 11

Fig. 1

Table 1

Table 2

Fig. 2

Table 3

Fig. 3

Fig. 4

Fig. 5

Fig. 6

Fig. 7

Table 4

References 18

[1]	张群, 范玮, 徐华胜. 中国脉冲爆震发动机技术研究现状及分析[J]. 航空发动机, 2013,39(3):18-22.
[2]	Fickett W, Davis W C. Detonation theory and experiment[M]. New York: Mineola, 1999: 1-10.
[3]	Lee J H S. The detonation phenomenon [M]. Cambridge: Cambridge University Press, 2008: 1-3.
[4]	Kessler D A, Gamezo V N, Oran E S. Simulations of flame acceleration and deflagration-to-detonation transitions in methane-air systems[J]. Combustion and Flame, 2010,157(11):2063-2077. doi: 10.1016/j.combustflame.2010.04.011
[5]	Heidari A, Ferraris S, Wen J X, et al. Numerical simulation of large scale hydrogen detonation[J]. International Journal of Hydrogen Energy, 2011,36(3):2538-2544. doi: 10.1016/j.ijhydene.2010.05.093
[6]	Wang Y H, Wang J P, Qiao W Y. Effects of thermal wall conditions on rotating detonation[J]. Computers and Fluids, 2016,140:59-71. doi: 10.1016/j.compfluid.2016.09.008
[7]	张薇, 刘云峰, 姜宗林. 气相爆轰波胞格尺寸与点火延迟时间关系研究[J]. 力学学报, 2014,46(6):977-981. doi: 10.6052/0459-1879-14-046
[8]	张德良, 谢巍, 郭长铭, 等. 气相爆轰胞格结构和马赫反射数值模拟[J]. 爆炸与冲击, 2001,21(3):161-167.
[9]	刘云峰, 王健平. 有限谱 ENO 格式在爆轰波数值模拟中的应用[J]. 爆炸与冲击, 2003,23(3):343-348.
[10]	Oran E S, Weber J W, Stefaniw E I, et al. A numerical study of a two-dimensional H$_{2}$-O$_{2}$-Ar detonation using a detailed chemical reaction model[J]. Combustion and Flame, 1998,113(1/2):147-163. doi: 10.1016/S0010-2180(97)00218-6
[11]	Fukuda M, Dzieminska E, Hayashi A K, et al. Effect of wall conditions on DDT in hydrogen-oxygen mixtures[J]. Shock Waves, 2013,23(3):191-200. doi: 10.1007/s00193-013-0444-9
[12]	董刚, 范宝春, 谢波. 氢气-空气混合物中瞬态爆轰过程的二维数值模拟[J]. 高压物理学报, 2004,18(5):40-46.
[13]	王昌建, 徐胜利. 直管内胞格爆轰的基元反应数值研究[J]. 爆炸与冲击, 2005,25(5):23-34.
[14]	张宝亮, 丁珏, 王庆涛, 等. 约束空间可燃气体燃烧爆轰特性的数值研究[J]. 中国安全生产科学技术, 2012,8(8):23-27.
[15]	Nettleton M A. Gaseous detonations: their nature, effects and control[M]. New York: Chap man and Hall, 1987: 30-31.
[16]	李雪松. 各向同性湍流大涡模拟中 Roe 格式适用性研究[J]. 工程热物理学报, 2015,36(11):2348-2351.
[17]	Bhattacharjee B, Schwer D A, Barton P I, et al. Optimally-reduced kinetic models: reaction elimination in large-scale kinetic mechanisms[J]. Combustion and Flame, 2003,135(3):191-208. doi: 10.1016/S0010-2180(03)00159-7
[18]	Turanyi T. Applications of sensitivity analysis to combustion chemistry[J]. Reliability Engineering and System Safety, 1997,57(1):41-48. doi: 10.1016/S0951-8320(97)00016-1
