矩形积分双谱和半监督鉴别分析下的通信辐射源识别

doi:10.12066/j.issn.1007-2861.1991

Abstract

Abstract:

This paper is an attempt towards coping with the problem that the methods of traditional communication emitter identification with the same model performs poorly with extracting fingerprint feature and acquiring high accuracy recognition when the priori label information is insignificant. Targeting the same manufacturer, same batch and same type communication emitter identification of small fingerprint feature difference, an efficient algorithm based on square integral bispectra and semi-supervised discriminant analysis is proposed for communication emitter identification. This algorithm uses square integral bispectra for the extraction of the communication emitter signal bispectra feature as the fingerprint feature, which represents the communication emitter. Simultaneously, for the purpose of improving communication emitter identification recognition performance, the semi-supervised discriminant analysis algorithm is employed to map high dimensional bispectra feature data to a low dimensional subspace and identify in the low dimensional subspace by the nonlinear manifold information and partial label information of bispectra feature data. In order to verify the effect of the proposed algorithm, the same manufacturer, same batch and same type FM radios, as representative communication emitter with the same model, are used here to perform identification experiment. Experiment results show the highest recognition rate of proposed method for test sample is up to 87.6% when the labeled training FM radio samples are limited, which points to the effectiveness of this algorithm in extracting fingerprint feature and recognition accuracy on same type communication emitter identification.

Key words: communication emitter identification, feature extraction, square integral bispectra, semi-supervised discriminant analysis

CLC Number:

TN911.7

Guochuan HAN, Jinyi ZHANG, Ke LI, Likang HE, Yuxi JIANG, Tao WANG. Communication emitter identification under square integral bispectra and semi-supervised discriminant analysis[J]. Journal of Shanghai University（Natural Science Edition）, 2019, 25(5): 722-732.

Figures/Tables 8

Fig. 1

Fig. 2

Table 1

Fig. 3

Fig. 4

Fig. 5

Table 2

Fig. 6

References 15

[1]	Huang G, Yuan Y, Wang X , et al. Specific emitter identification based on nonlinear dynamical characteristics[J]. Canadian Journal of Electrical and Computer Engineering, 2016,39(1):34-41.
[2]	Dudczyk J, Kawalec A . Fractal features of specific emitter identification[J]. Acta Physica Polonica, 2013,124(3):406-409.
[3]	Liang K, Huang Z, Hu D , et al. An individual emitter recognition method combining bispectrum with wavelet entropy[C]// IEEE International Conference on Progress in Informatics and Computing. 2015: 206-210.
[4]	Lin C M, Chen Y M, Hsueh C S . A self-organizing interval type-2 fuzzy neural network for radar emitter identification[J]. International Journal of Fuzzy Systems, 2014,16(1):20-30.
[5]	桂云川, 杨俊安, 万俊 . 基于双谱特征融合的通信辐射源识别算法[J]. 探测与控制学报, 2016,38(5):91-95.
[6]	雷迎科, 郝晓军, 韩慧 , 等. 一种新颖的通信辐射源个体细微特征提取方法[J]. 电波科学学报, 2016,31(1):98-105.
[7]	齐建文, 陈慧贤, 吴彦华 , 等. 通信辐射源信号细微特征分析与处理 [M]. 北京: 国防工业出版社, 2015.
[8]	何永亮, 陈西豪, 许华 , 等. 利用信号围线积分双谱分形特征实现电台识别[J]. 电讯技术, 2014,54(10):1354-1359.
[9]	官建平 . 基于双谱的辐射源个体识别技术[D]. 西安: 西安电子科技大学, 2014.
[10]	Feng J, Wang J, Zhang H G , et al. Fault diagnosis method of joint fisher discriminant analysis based on the local and global manifold learning and its kernel version[J]. IEEE Transactions on Automation Science and Engineering, 2016,13(1):122-133.
[11]	Yan H B, Lu J W, Zhou X Z , et al. Multi-feature multi-manifold learning for single-sample face recognition[J]. Neurocomputing, 2014,143(16):134-143.
[12]	Guo X, Yun T, Qi L , et al. A novel semi-supervised dimensionality reduction framework for multi-manifold learning[J]. IEEE Multimedia, 2016,23(2):28-41.
[13]	Vural E, Guillemot C . Out-of-sample generalizations for supervised manifold learning for classification[J]. IEEE Transactions on Image Processing A Publication of the IEEE Signal Processing Society, 2016,25(3):1410-1424.
[14]	Cai D, He X F, Han J W . Semi-supervised discriminant analysis[C]// IEEE International Conference on Computer Vision. 2007: 1-7.
[15]	李婷, 程博, 尤淑撑 . 基于半监督鉴别分析的高分辨率 SAR 影像建筑区提取[J]. 遥感技术与应用, 2016,31(2):239-246. doi: doi:10.11873/j.issn.1004-0323.2016.2.0239
