一种低延迟的无虚通道NoC容错路由算法

doi:10.12066/j.issn.1007-2861.1918

Journal of Shanghai University（Natural Science Edition） ›› 2019, Vol. 25 ›› Issue (2): 189-197.doi: 10.12066/j.issn.1007-2861.1918

• Research Articles • Previous Articles Next Articles

A low-latency fault-tolerant routing algorithm for NoC without

virtual channelsLI Jiao^1,², XU Haipeng¹, CHONG Yunfeng¹, LIU Peng¹, RAN Feng^1,²()

^1. Microelectronic Research and Development Center,Shanghai University,Shanghai 200444, China
^2. Key Laboratory of Advanced Display and System Application,Shanghai University,Shanghai 200444, China

Received:2017-04-24 Online:2019-04-30 Published:2019-05-05
Contact: Feng RAN E-mail:ranfeng@shu.edu.cn

Abstract

Abstract:

As the characteristic size becomes smaller, network on chip (NoC) is prone to faults. To improve fault-tolerant ability of NoC and reduce network latency, a low-latency fault-tolerant routing algorithm without using virtual channels is presented. Based on a turn model,the algorithm uses a bypass structure to keep a fixed direction connection of fault nodes. This way can reduce packet latency and deal with arbitrary amount and arbitrary distribution of fault nodes. Simulation results in an 8$\times $8 2D-Mesh NoC show that,compared with two reference algorithms, the proposed algorithm can reduce average latency by 4.35% and 20.20% with a single fault node and a communication load of 30%. It can also effectively deal with multiple faults.

Key words: network on chip (NoC), fault-tolerant, low-latency, routing algorithm, bypass structure

CLC Number:

TP393

virtual channelsLI Jiao, XU Haipeng, CHONG Yunfeng, LIU Peng, RAN Feng. A low-latency fault-tolerant routing algorithm for NoC without[J]. Journal of Shanghai University（Natural Science Edition）, 2019, 25(2): 189-197.
