环境对高熵合金Al$_{\textbf{0.1}}$CoCrFeNi力学性能的影响

doi:10.12066/j.issn.1007-2861.1915

Abstract

Abstract:

Effects of the environment on mechanical properties of Al$_{0.1}$CoCrFeNi alloy when tested in vacuum, air and gaseous hydrogen at different pressures were investigated. The result shows that a few hydrogen atoms can significantly improve elongation of the Al$_{0.1}$CoCrFeNi alloy when tested in air and gaseous hydrogen. The elongation of Al$_{0.1}$CoCrFeNi alloy increases with the increase of pressure of gaseous hydrogen. The increase rate of elongation becomes slower when the pressure of gaseous hydrogen is more than 0.010 MPa. Fractographs of Al$_{0.1}$CoCrFeNi alloy exhibits all transgranular fracture patterns. Some micro-voids exist on the fractograph surfaces when tensile test is performed in three environments.

Key words: Al$_{0.1}$CoCrFeNi alloy, tensile properties, environmental effect

CLC Number:

TG111
TG146

QIANG Xiaoni, CHEN Yexin, ZHANG Jiantao. Effects of environment on mechanical properties of Al$_{\textbf{0.1}}$CoCrFeNi alloy[J]. Journal of Shanghai University（Natural Science Edition）, 2019, 25(2): 206-214.

Figures/Tables 7

Fig. 1

Fig. 2

Fig. 3

Table 1

Fig. 4

Fig. 5

Fig. 6

References 16

[1]	叶均蔚, 陈瑞凯, 刘树均 . 高熵合金的发展概况[J]. 工业材料杂志, 2005,22(4):71-75.
[2]	Yeh J W, Chen S K, Lin S J , et al. Nanostructured high-entropy alloys with multiple principal elements: novel alloy design concepts and outcomes[J]. Advanced Engineering Materials, 2004,6(5):299-303. doi: 10.1002/(ISSN)1527-2648
[3]	Yeh J W . Recent progress in high-entropy alloys[J]. European Journal of Control, 2006,31(6):633-648.
[4]	Tsai M H, Yeh J W . High-entropy alloys: a critical review[J]. Materials Research Letters, 2014,2(3):107-123. doi: 10.1002/adma.201806236 pmid: 30838717
[5]	万晓景, 朱家红, 黄胜标 . Fe3Al与水汽及氧气的表面反应[J]. 金属学报, 1995,31(16):183-187.
[6]	Chen Y X, Wan X J, Xu W X . Surface reaction of TiAl with water vapor or oxygen[J]. Journal of Meterials Science and Technology, 2003,19(4):334-336. doi: 10.1590/s0102-865020190100000002 pmid: 31826148
[7]	Lee K H, Lukowski J T, White C L . Effect of gaseous hydrogen and water vapor pressure on environmental embrittlement of Ni3Al[J]. Intermetallics, 1997,5(6):483-490. doi: 10.1016/S0966-9795(97)00020-4
[8]	陈业新 . 金属间化合物的环境氢脆[J]. 上海大学学报(自然科学版), 2011,17(4):487-502. doi: 10.3969/j.issn.1007-2861.2011.04.016
[9]	马杰, 陈业新 , Liu C T . 硼对有序态Ni3Fe合金氢气环境中氢脆敏感性的影响[J]. 南京大学学报(自然科学), 2009,45(2):241-247.
[10]	杜艳艳 . 多主元合金的微结构及性能研究[D]. 大连: 大连理工大学, 2011.
[11]	Wang W R, Wang W L, Wang S C , et al. Effects of Al addition on the microstructure and mechanical property of AlxCoCrFeNi high-entropy alloys[J]. Intermetallics, 2012,26:44-51. doi: 10.1016/j.intermet.2012.03.005
[12]	Komarasamy M, Kuman N, Tang Z , et al. Effect of microstructure on the deformation mechanism of friction stir-processed Al0.1CoCrFeNi high entropy alloy[J]. Materials Research Letters, 2015,3(1):30-34. doi: 10.1080/21663831.2014.958586
[13]	Wang Y P, Li B S, Ren M X , et al. Microstructure and compressive properties of AlCrFeCoNi high entropy alloy[J]. Materials Science and Engineering: A, 2008,491(1/2):154-158. doi: 10.1038/s41598-019-43329-w pmid: 31043686
[14]	Fang S C, Chen W P, Fu Z Q . Microstructure and mechanical properties of twinned Al0.5CrFeNiCo0.3C0.2 high entropy alloy processed by mechanical alloying and spark plasma sintering[J]. Materials and Design, 2014,54:973-979. doi: 10.1016/j.matdes.2013.08.099
[15]	Gali A, George E P . Tensile properties of high- and medium-entropy alloys[J]. Intermetallics
	2013,39:74-78.
[16]	Shun T T, Du Y C . Microstructure and tensile behaviors of FCC Al0.3CoCrFeNi high entropy alloy[J]. Journal of Alloys and Compounds, 2009,479(1/2):157-160. doi: 10.1016/j.jallcom.2008.12.088
