上海大学学报(自然科学版) ›› 2022, Vol. 28 ›› Issue (5): 813-820.doi: 10.12066/j.issn.1007-2861.2445

• • 上一篇    下一篇

氧化钇钡铜(YBCO)高温超导带材在超导储能装置的应用

彭思思1,2, 蔡传兵1(), 郑军2, 郭树强3, 徐颖3, 周迪帆1

  1. 1.上海大学 理学院, 上海 200444
    2.武汉船用电力推进装置研究所, 湖北 武汉 430064
    3.华中科技大学 电气与电子工程学院, 湖北 武汉 430074
  • 收稿日期:2022-09-02 出版日期:2022-10-30 发布日期:2022-11-12
  • 通讯作者: 蔡传兵 E-mail:cbcai@t.shu.edu.cn
  • 作者简介:蔡传兵(1954—), 男, 教授, 博士生导师, 博士, 研究方向为高温超导带材及应用. E-mail: cbcai@t.shu.edu.cn
  • 基金资助:
    中科院先导专项(XDB25000000);国家自然科学基金资助项目(52172271)

Application of YBCO high temperature superconducting tapes in superconducting energy storage devices

PENG Sisi1,2, CAI Chuanbing1(), ZHENG Jun2, GUO Shuqiang3, XU Ying3, ZHOU Difan1

  1. 1. Shanghai Key Laboratory of High Temperature Superconductors, Department of Physics, Shanghai University, Shanghai 200444, China
    2. WuHan Institute of Marine Electric Propulsion, Wuhan 430064, Hubei, China
    3. Huazhong University of Science and Technology, Wuhan 430064, Hubei, China
  • Received:2022-09-02 Online:2022-10-30 Published:2022-11-12
  • Contact: CAI Chuanbing E-mail:cbcai@t.shu.edu.cn

摘要:

高温超导磁储能系统具有功率密度大、响应快和寿命长等优势, 在新能源电网和新能源电动船舶等领域具有潜在的应用前景. 二代高温超导带材具有优越的载流能力、较高的工作温度以及相对较低的制备成本, 在超导储能装置得领域到了广泛应用. 对氧化钇钡铜(YBCO)高温超导带材特性介绍的基础上, 分析储能装置对其的性能要求, 阐述一代高温超导储能磁体研究现状, 并结合 10 MJ 储能磁体的设计进行具体案例分析.

关键词: 超导储能, 二代高温超导带材, 10 MJ 储能磁体

Abstract:

High-temperature Superconducting Magnetic Energy Storage system has the advantages of high power density, fast response and long life. It has potential application prospects in the fields of new energy grids and new energy electric ships. Due to the superior current-carrying capacity, high operating temperature, and relatively low fabrication cost of second-generation high-temperature superconducting tapes, they are widely used in superconducting energy storage devices. In this paper, based on the introduction of YBCO high temperature superconducting tape, the performance requirements of energy storage devices is analyzed, and a specific case analysis has been carried out in combination with the design of 10 MJ energy storage magnets.

Key words: Superconducting energy storage, second generation high temperature superconducting tape, 10 MJ energy storage magnet
